1、WOBICOM G6000 5G-A & WiFi-6 Smart Router System (CPE) , is based on brand-new embed platform , it can be satisfied withgrowing-up mobile connections requirements and provides the fast speed beyond your imagination . 2、The CPE is compatible with NSA/SA dual-mode , suits to all network types all over the world , it means you justplug and play it and enjoy the ultra-fast broadband connection at any places . 3、The CPE brings the new way to enable you experience VR/AR/4K/8K streaming freely and easily . With 802 .11ax(Wi-Fi 6) technology built-in , the single CPE has wider wireless coverage and more bandwidth . Meanwhile the CPEbrings higher security and better network efficiency .
Technical Specifications
| Model | G6000 | ||||||
| 5G Module | SDX62-GL | ||||||
| CPU | MT7981BA+MT7976CN+MT7531AE（ Dual-core A53 1 .3GHz） | ||||||
| WiFi Frequency | 2.4G / 5G Downlink Cat 19/ Uplink Cat 18 | ||||||
| Storage | 512MB DDR3 + 128MB SPI NAND FLASH | ||||||
| WiFi Standard | IEEE 802.11b 、g 、a 、n 、ac 、ax IEEE 802.3 、u 、x | ||||||
| WiFi | 2.4GHz 2TR: 600Mbps , 5GHz 2T2R: 2402Mbps | ||||||
| 5G NR | 3GPP Release 16 NSA/SA operation, Sub-6 GHz | ||||||
| 5G Network Mode | NSA/SA | ||||||
| 5G/4G Data Rate | 5G SA Transmission Speed:2 .1Gbps/900Mbps (up to ISPs) 5G NSA Transmission Speed:2 .5Gbps/650Mbps (up to ISPs) LTE : Down 1 .0 Gbps ；UP 200 Mbps | ||||||
| 5G Frequency Bands | 5G NR NSA / SA Sub-6 n1/2/3/5/7/8/12/13/14/18/20/25/26/29/30/34/38/39/40/41/46/53/66/67/68/70/71 /75/76/77/ 78/79/90/91/91/92/93/94 mmWave n257/258/260/261 LTE FDD B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/70/71/75/76 LTE TDD B34/38/39/40/41/48/46/53 WCDMA B1/2/3/4/5/6/8/9/19 | ||||||
| Working mode | AP / Router / Repeater | ||||||
| Wireless security | Wireless MAC address filtering 64/128 bit WEP encryption WPA-PSK 、WPA2-PSK 、WPA3-SAE 、WPA/WPA2-PSK 、WPA2-PSK/WPA3-SAE WPS（ PBC ） | ||||||
| Other features | Wireless host status display Wireless site scanning Seamless roaming between nodes Seamless roaming between bands | ||||||
| Interface | 1 x 10/100M/1000M WAN port , support Auto MDI/MDIX 2 x 10/100M/1000M LAN ports , support Auto MDI/MDIX 2 Nano SIM card slots , 1 eSIM card (customized) | ||||||
| WiFi settings | WiFi basic settings (dual-band integration , switch , wireless mode , SSID , PWD , encryption algorithm , channel , bandwidth , power adjustment) . Advanced settings (wireless client isolation , 802 .11h , WMM multimedia acceleration) . Multiple SSIDs (SSIDs , encryption methods , PWDs , and encryption algorithms) | ||||||
| Button | Mesh (press 1 second) . Reset (press and hold for 5 seconds) . | ||||||
| LED Indicator | 5G , 4G , WIFI signal indicator , power indicator | ||||||
| Power supply | DC 12V/2A | ||||||
| Network settings | Data Switch , Roaming Switch , Mode Selection , Default APN Information , and APN Manual Configuration FAILOVER switches : PPPOE , DHCP , and static 4G/5G band locking | ||||||
| Wifi settings | Wifi name and password , wifi timing , channel bandwidth setting , power regulation , bridging function ,OFDMA , Mesh | ||||||
| SMS feature | SMS sending and receiving , SMS center settings , USSD | ||||||
| Guest network | Configure the SSID , rate limit , and startup time limit of the guest network | ||||||
| Parental controls | Online device display , online time , restricted Internet time period , URL filtering configuration | ||||||
| Advanced settings | Working Mode , SIM PIN , Mobile Data Switch , Bandwidth Control , Sleep Mode , LED Control , Filter MAC Address , Firewall , Static Routing , DDNS , Virtual Server , DMZ Host , UPnP , TR069 Settings | ||||||
| System settings | System Status , Time Setting , Password Management , Configuration Management , Firmware Upgrade ,Scheduled Restart , System Log , LAN Setting , DHCP Binding , Reboot & Reset , Remote Management | ||||||
| Use environment | Operating temperature : -20。C to 50。C Storage temperature : -40。C to 70。C Operating humidity : 10% to 90% RH non-condensing Storage humidity : 5% to 95% RH non-condensing | ||||||
| eSIM | Optional | ||||||
| SIM Card | Dual Sim |
