1.WOBICOM M-X6 5G Smart Router System (ODU), is based on brand-new embed platform, it can be satisfied with growing-up mobile connections requirements and provides the fast speed beyond your imagination.2. The CPE is compatible with NSA/SA dual-mode, suits to all network types all over the world, it means you just plug and play it and enjoy the ultra-fast broadband connection at any places. 3.Outdoor 5G ODU, the waterproof level is up to IP67, the appearance is exquisite and beautiful, and it is suitable for various installation methods: wall hanging, pole holding.
Technical specifications
| Model | M-X6 | ||||||||||
| CPU | RM520N-GL | ||||||||||
| 5G NR | 3GPP Release 17 NSA/SA operation | ||||||||||
| 5G Network Mode | NSA/SA | ||||||||||
| 5G/4G Data Rate | 5G SA Sub-6 DL: 7.01 Gbps; UL: 1.25 Gbps 5G NSA Sub-6 DL: 5.47 Gbps; UL: 730 Mbps LTE DL: 2 Gbps; UL: 211 Mbps WCDMA DL: 42 Mbps; UL: 5.76 Mbps | ||||||||||
| 5G Frequency Bands | 5G NR NSA / SA 1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/78/79 5G NR SA n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/78/79 | ||||||||||
| 4G&3G Frequency Bands | LTE-FDD B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 66/ 71 LTE-TDD：B34/B38/B39/B40/B41/B42/B43/B48 LAA：B46 WCDMA ：B1/B2/B4/B5/B8/B19 | ||||||||||
| Dimension | 145X130X45MM | ||||||||||
| Interface | 1*10/100M/1000/2500Mbps LAN 1 Reset Button 2 SIM card slot | ||||||||||
| Reset | Reset （Long press 10 seconds to restore the factory settings） | ||||||||||
| LED Indicator | Battery power,RF Signal, SIM Signal,SYS Signal | ||||||||||
| Power Consumption | < 24W （POE 48V/1A） | ||||||||||
| Software Function | IPV6/IPV4,TTL settings,AT command,Modify I MEI,Lock Band,Lock Cell,SMS,IP Passthrough,Zerotier,TR-069,Smart QoS,Guest WiFi,Remote web,Firewall,Domain ACL,UPnP,VPN （L2TP/PPTP/Wireguard/GRE/IPsec/OpenVpn） | ||||||||||
| Environment | Operating Temperature： -20℃ ~ +50℃ Storage Temperature:-40℃ ~ +70℃ Humidity： 5％ ～95％ （Non condensation） | ||||||||||
| Weight | 1.8KG （Includes color box accessories） | ||||||||||
